miniature beam profiler

Reference: DAT-BladeCam-HR

The Beam Profiler BladeCam-HR is suitable with a housing depth of only 6.5 mm suited for beam profile analysis at locations with limited space.






Alexandre Besson
Business Unit Director
+33 5 57 10 92 84
a.besson@laser2000.fr
Product request: miniature beam profilerX



Dear Besson,

I am interested in the following product: miniature beam profiler

I am interested in:

an offer
Information material
a call back and consulting
Please complete at least the mandatory fields marked with *.



* Title:

Academic Degree:

First Name:

* Last Name: * Last Name:

* Company Name: * Company Name:

Company Address:

* Street: * Street:

* Zip Code: * Zip Code:

* City: * City:


* E-Mail: * E-Mail:

* Phone: * Phone:

Text:



* What do you see in picture 2?* What do you see in Picture 2?

laserdiode laserschutzbrille laserschutzfenster leistungsmessgerät


Bitte auswählen:Please select:    Diode    Gauge    Safety Goggles    Safety Windows



Please check red marked fields.




Your request has been sent successfully. You will be contacted as soon as possible.




Product description
0.65" Thin! Portable, Port-Powered, USB 2.0,
Beam Profiling for Windows XP & Vista, Intel-Mac

Features:

- USB 2.0 port-powered; flexible 3 m cable; no external power supply required.
- 0.65", (16.5 mm), Ultra-thin (includes ND filter) to fit tight beam trains [0.50"/12.5 mm without filter]
- 10 Bit Digital CMOS cameras with on-chip 10-bit ADC
- Window-free sensors standard for no fringing
- 20,000:1 electronic auto-shutter, 50 ?s -1000 ms
- Parallel capture on multiple cameras
- Field-replaceable image sensors
- X-Ray, UV, 1310 nm (p.4) & 1475-1680 nm (p.4)
- High Resolution: 1.3 MPixel, 1280 x 1024, 5.2 ?m2, 6.6 x 5.2 mm

Applications

- CW laser profiling
- Field servicing of lasers and laser-based systems
- Optical assembly & instrument alignment
- Beam wander & logging
