HeNe Laser Replacement View larger

HeNe Laser Replacement

Reference: IPS-L2K-HeNe-Replacement

Innovative Photonic Solution’s proprietary Ultra-Stable Diode-Based HeNe Laser features high output power with ultra-narrow spectral bandwidth and a circularized and collimated output beam.






Alexandre Besson
Business Unit Director
+33 5 57 10 92 84
a.besson@laser2000.fr
Product request: HeNe Laser ReplacementX



Dear Besson,

I am interested in the following product: HeNe Laser Replacement


I am interested in:

an offer
Information material
a call back and consulting
Please complete at least the mandatory fields marked with *.



* Title:

Academic Degree:

First Name:

* Last Name: * Last Name:

* Company Name: * Company Name:

Company Address:

* Street: * Street:

* Zip Code: * Zip Code:

* City: * City:


* E-Mail: * E-Mail:

* Phone: * Phone:

Text:




* What do you see in picture 2?* What do you see in Picture 2?

laserdiode laserschutzbrille laserschutzfenster leistungsmessgerät


Bitte auswählen:Please select:    Diode    Gauge    Safety Goggles    Safety Windows



Please check red marked fields.




Your request has been sent successfully. You will be contacted as soon as possible.





Product description
Innovative Photonic Solution’s proprietary Ultra-Stable Diode-Based HeNe Laser features high output power with ultra-narrow spectral bandwidth and a circularized and collimated output beam. Designed to replace HeNe lasers, the Ultra-Stable Diode-Based HeNe Laser offers superior wavelength stability over time & temperature (< 1.5 pm drift over 20C case temperature change), and offers significantly lower power consumption and resultant heat generation than traditional HeNe sources. In addition, the Ultra-Stable Diode-Based HeNe Laser offers significantly longer coherence length than traditional HeNe lasers (over 5 meters versus 0.25 meters) – making this source ideal for interferometric applications

The I0633SD00xxB comes standard with a circularized and collimated output beam, internal thermistor & TEC, and ESD protection. Lasing wavelength can be accurately specified and repeatedly manufactured to within 0.1 nm and is available at 633 nm, 638 nm, 640 nm, 658 nm, 660 nm, 780 nm, 785 nm, 808 nm, 830 nm, and 1064 nm. The laser is ideal for interferometry, particle sizing, Dynamic Light Scattering (DLS), and other interferometry & metrology applications.

Features:

  • High Power Single Mode Output (>2 mW - 60 mW)
  • Short Term Wavelength Stability < 0.5 pm
  • Ultra-Narrow Spectral Bandwidth (< 1 MHz)
  • Ultra-Stabilized Output Spectrum
  • Circularized & Collimated Output Beam
  • Integral Thermistor & TEC
  • Integral ESD Protection

Downloads - HeNe Laser Replacement
