Product description

The CNI series cw diode lasers are available with nearly all commercial available wavelengths. In many cases the optical output power reaches the technical limit having a compact housing and a high reliability at the same time. As options TTL or analog modulations are available as well as fiber couplings.

Applications: Fluorescence Excitation, Illumination, Laser-Show

Wavelengths and powers:


Wavelength [nm]Power
3751 - 150 mW
3951 - 100 mW
3971 - 100 mW
4001 - 400 mW
4051 mW - 10 W
4101 mW - 10 W
4151 - 400 mW
4421 - 1000 mW
4451 mW - 20 W
4471 mW - 20 W
4501 mW - 20 W
4541 - 80 mW
4601 - 1200 mW
4621 mW - 15 W
4651 - 800 mW
4881 - 150 mW
5101 - 30 mW
5151 - 30 mW
5201 mW - 10 W
6221 - 50 mW
6271 - 100 mW
6331 - 100 mW
6351 mW - 6 W
6371 mW - 5 W
6401 - 1000 mW
6421 - 1000 mW
6551 mW - 5 W
6601 - 1500 mW
6801 - 1000 mW
6851 - 50 mW
6901 - 1000 mW
7051 - 25 mW
7301 - 1500 mW
7501 mW - 2 W
7851 mW - 2.5 W
7931 mW - 5 W
8001 mW - 2.5 W
8081 mW - 10 W
8101 mW - 10 W
8251 mW - 2.5 W
8301 mW - 2.5 W
8451 - 50 mW
8521 mW - 2 W
8791 mW - 2.5 W
8801 mW - 2.5 W
8851 mW - 2 W
9051 - 200 mW
9151 mW - 8 W
9401 mW - 8 W
9651 mW - 2 W
9751 mW - 10 W
9801 mW - 10 W
10601 mW - 2.5 W
10641 mW - 2.5 W
13101 - 20 mW
14401 mW - 3.5 W
14501 mW - 3.5 W
14701 mW - 3.5 W
15321 mW - 3.5 W
15501 mW - 3.5 W
18701 - 800 mW
19001 - 800 mW
19401 - 800 mW
22001 - 450 mW

More wavelengths are available as DPSS lasers.
