Reference: LYT-THz-Laser

Láser de terahercios (THz) de la máxima fiabilidad, alta potencia y válido para todo tipo de aplicaciones






Alexandre Besson
Business Unit Director
+33 5 57 10 92 84
a.besson@laser2000.fr
Product request: THz LaserX



Dear Besson,

I am interested in the following product: THz Laser

I am interested in:

an offer
Information material
a call back and consulting
Please complete at least the mandatory fields marked with *.



* Title:

Academic Degree:

First Name:

* Last Name: * Last Name:

* Company Name: * Company Name:

Company Address:

* Street: * Street:

* Zip Code: * Zip Code:

* City: * City:


* E-Mail: * E-Mail:

* Phone: * Phone:

Text:



* What do you see in picture 2?* What do you see in Picture 2?

laserdiode laserschutzbrille laserschutzfenster leistungsmessgerät


Bitte auswählen:Please select:    Diode    Gauge    Safety Goggles    Safety Windows



Please check red marked fields.




Your request has been sent successfully. You will be contacted as soon as possible.




Product description
Maximum reliability

The TeraCascade laser uses the most reliable components available on the market. For example the cryo-cooler is rated for 200.000 hours of MTBF, which is equivalent to more than 23 years of 24/7 operation.

Focused on output quality

The beam quality of a laser source is a crucial point, in particular for imaging application. The TeraCascade laser offers a quasi-Gaussian beam profile and a low beam divergence for an optimal imaging capability.

Ready, whatever your application is

Versatility is one of the most important aspects. To achieve maximum flexibility in your application, we have designed a custom laser driver based on several years of user feedback. This allows you to develop any kind of applications.

Specifications:

- Integrated driver, provides both CW and pulsed operation.
- Powerful, with >1mW of average power around 2.5 THz.
- Automatic power on/off procedure, “turn-key” system.
- 4.3” touchscreen interface, to fully control the parameters:
--Output power
--Pulse frequency
--Duty cycle
--Driving current
- Compact, volume comparable to two shoeboxes.
- Light, weighs less than 10 Kg.
- Portable, with two handles integrated in the box.
- Fully connected, with BNC TTL connectors, allowing a full user control of the laser driver:
-- Laser in
-- Gate in
-- Ref in
-- Ref out
-- Gate out
- Easy setup integration, with a USB port to control it via a PC (Labview VIs).
